Do I need a ground fault circuit interrupter?

The NEC requires GFCIs on all exterior and bathroom receptacles (another term for outlets). GFCIs are also required on all receptacles serving kitchen countertops. In laundry rooms and utility rooms, GFCIs should be installed on outlets within six feet of sinks, washing machines, and water heaters.

Is ground fault protection the same as GFCI?

A ground-fault circuit-interrupter (GFCI) is an electrical device, either a receptacle or circuit breaker, which is designed to protect people from electric shock. GFCI protection should not be confused with ground-fault protection for equipment or grounding in general.

What happens when a GFCI fails?

When a GFCI trips, it won’t supply power, so your hair dryer or power saw won’t work, and if a tripped GFCI is at the beginning of a circuit, it will cut power to the entire circuit, so other outlets and lights on the circuit won’t work either.

How much does a GFCI plug cost?

For a single GFCI-protected outlet, be prepared to pay $135 to $150 in total. You can make the most of this cost by following the local building codes to find your exact GFCI protection needs.

Can you replace regular outlet with GFCI?

You can replace almost any electrical outlet with a GFCI outlet. Correctly wired GFCIs will also protect other outlets on the same circuit. While it’s common to find GFCI outlets in bathrooms and kitchens, there are GFCI outlet requirements.

How fast does it take for a GFCI to trip?

The GFCI will “sense” the difference in the amount of electricity flowing into the circuit to that flowing out, even in amounts of current as small as 4 or 5 milliamps. The GFCI reacts quickly (less than one-tenth of a second) to trip or shut off the circuit.

Where should a ground fault circuit interrupter be installed?

The National Electrical Code (NEC) requires GFCI outlets in all wet or damp locations. For your home to be up to code, working GFCI outlets must be installed in your bathrooms, kitchens and laundry rooms.

Can I use AFCI instead of GFCI?

Yes, they both can be used on the same circuit; however, the Dual Function AFCI/GFCI Receptacle offers the option of providing both AFCI and GFCI protection in a single device.

Can you install a GFCI outlet yourself?

After you have removed the old outlet, you can begin replacing it with the new GFCI outlet. Using your needle nosed pliers or wire cutter, make sure the wires are straight and able to be put into the new GFCI outlet. As you begin, turn the outlet over. You only want to be rewiring your GFCI outlet into the line screws.

Where can I find a GFCI outlet?

How to Locate a GFCI Receptacle

Go to the kitchen, bathroom, garage, crawl spaces, unfinished basement and outdoor outlets and plug in the outlet tester.
Locate the breaker box.
Turn off the breakers one at a time.
Search for any GFCI outlets.
Press the test button to deactivate any outlets loading off the GFCI unit.
