How does a smoke control system work

They pressurize a certain area such as a stairwell, elevator, vestibule, or zone of a building by using a mechanical fan. This pressure difference across a barrier ensures that smoke does not migrate into certain areas of a building.

What are the three types of smoke control system?

use some type of ventilation system for smoke control. While there are many types that you can use on your property for smoke control, three types are the most common and widely used in most buildings and premises. These three options include smoke, natural, and mechanical ventilation system.

What is an active smoke control system?

Active smoke management systems typically utilize smoke exhaust or evacuation systems. These systems utilize mechanical equipment to control the spread of smoke. Exhaust inlets located near or in the ceilings remove smoke from the building to allow people to evacuate.

What is the difference between a smoke control system and a smoke management system?

Smoke control systems are one of the most complicated and often misunderstood systems within a facility, and rightfully so. … Conversely, Smoke Management Systems are used during post fire events to remove smoke from a facility and/or restrict smoke from entering specific area’s of a facility during general evacuation.

Why do buildings have smoke control systems?

The purpose of smoke control is to reduce the build-up of smoke within an enclosed space in order to provide the occupants of the space sufficient time to evacuate to a safer area of the building or to exit the building.

What is smoke control testing?

The operational testing involves manipulation of manual override controls and activation of detection devices, fans, and dampers, where provided. The IFC, provides a description of the required testing which must include all smoke control related equipment such as initiating devices, fans, dampers and controls.

Where are smoke control systems required?

The two most common systems that are required by the IBC are atrium smoke control (IBC Section 402) and smokeproof enclosures (IBC Section 403) required for stairwells in high-rise buildings. Specifically, the IBC requires an atrium smoke control system when an atrium is connecting more than two floors.

How do you control smoke in a building?

1. Dilution. Dilution is the method of removing smoke from cool smoke zones through the introduction of make-up air (clean air that’s ventilated in) coupled with exhaustion. …
2. Pressurization. …
3. Buoyancy. …
4. Compartmentation.

How can the HVAC system be used for smoke control?

Methods of smoke control that will be encountered include pressurization method, exhaust method, airflow method, air-change method, and positive pressurization method used in smokeproof and exit enclosures.

What is engineered smoke control system?

Engineered Smoke Control Systems are designed to detect and redirect smoke, significantly reducing its harmful effects and allowing additional time for occupants to evacuate. … Engineered Smoke Control Systems are a key installation in many commercial buildings to safeguard occupants’ safety.

Article first time published on

How can we control smoke from fire circulating in the building?

1. WHY FIRE AND SMOKE CONTROL IS IMPORTANT? Fire Dampers are required by all building codes to maintain the required fire resistance ratings of walls, partitions, and floor when they are penetrated by air ducts or other ventilation openings. …
2. FIRE DAMPERS. …
3. SMOKE DAMPERS. …
4. COMBINATION FIRE SMOKE DAMPERS.

What is a pressurized stairwell?

When there’s a fire in a building, a Stair Pressurization Fan forces clean, outside air into a stairwell to prevent smoke from cutting off the escape route. … The pressurized air helps people escape the fire and firefighters battle the fire.

What is a smoke reservoir?

Smoke reservoirs are areas where smoke is contained – they are required to limit the spread of smoke through a building. … These barriers are arranged to limit the size of the smoke reservoir at high level to control the amount of smoke spread in the building.

How are smoke dampers activated?

Smoke dampers are usually installed by sheet metal contractors. Smoke dampers can be activated by the fire alarm system, usually initiated by smoke detectors, or interlocked with a fire suppression system.

What is lobby relief?

Lobby relief fans are basically used to relieve pressure from stairwells and act as a smoke exhaust path in the event of a fire in a building. … All three VSDs will be operating in Override (fire) mode which allows them to ignore non-critical faults and runs to destruction.

What is the purpose of lift pressurization fan?

Lift Pressurisation Fans are need of the hour, they are used to pressurise the lift shaft. These Fans play a vital role in safety during a fire. These are Manufactured from heavy duty mild steel material and best in class Impellers to provide optimum pressurised air to maintain positive pressure in lift shaft.

Are smoke dampers normally open or closed?

During normal operation the pressure under the floor is maintained by modulating the damper mounted in the shaft wall. If a fire occurs and the temperature at the damper reaches 165°F (74°C), then the damper closes. If smoke is present in duct (or space area), then damper closes.

Do fire smoke dampers require power?

Motorized actuators are normally used for the operation of smoke dampers. The designer must consider the case where there is loss of normal power to the damper actuator. Either emergency power should be provided or smoke dampers should be arranged for fail-safe closure upon failure of power to the actuator.

Are smoke dampers required in smoke partitions?

Smoke dampers are required at penetrations of smoke barriers, unless the HVAC system is fully ducted and there is a sprinkler system installed throughout the facility, in which case they are not required. Smoke dampers are also required in air transfer openings (non-ducted) in smoke partitions.
