How wide are deck boards

Common deck board widths are 4”, 6” and 8”. The widths are readily available in most lumber or building supply stores, and the number of pieces easily calculated into deck dimensions. Other widths may be used for aesthetics and effect.

What width do decking boards come in?

Decking widths typically range from 90mm to 150mm, with 120mm and 140mm in between.

How wide is a 1x6 deck board?

The same is true of pine. A 1×6, for example, actually measures 3/4″ x 5 1/2″.

How wide is a 5 4 deck board?

Nominal SizeActual Size5/4 × 61″ × 5-1/2″6/4 × 61-5/16″ × 5-1/2″

How wide is a 2x6 deck board?

2×6 Decking is Thicker Than 5/4 Both with a deceptively different material thickness. 2×6 Deck Boards actual Dimensions 1.5″ x5. 5.” 5/4 Decking Actual Dimensions 1″ x 5.5.”

How far apart do you space deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

Are wider deck boards better?

Narrower boards work best. 4” nominal (3-1/2” actual) wide deck boards perform better than wider (6” nominal) deck boards. Because there are more gaps between the deck boards, 4” nominal deck boards provide about 44% more top of deck ventilation than 6” nominal decking.

What is the actual width of a 4x4?

Nominal SizeActual Size2 x 101 1/2 x 9 1/4 inches (38 x 235 mm)2 x 121 1/2 x 11 1/4 inches (38 x 286 mm)4 x 43 1/2 x 3 1/2 inches (89 x 89 mm)4 x 63 1/2 x 5 1/2 inches (89 x 140 mm)

Why do they call it 5 4 decking?

It simply refers to how many 1/4-inches thick the rough stock is. For example, 4/4 (read out loud as four-quarters) is 1-in. thick in the rough. 5/4 is 1-1/4-in.

How far can 5 4 deck boards span?

Decking Board Considerations Decking boards span from joist to joist. If you use 5/4 decking, joists must be no farther apart than 16 inches. Decking made of 2x4s or 2x6s can span up to 24 inches. If you will run decking at an angle, you might need to put the joists closer together.

Article first time published on

Can I use 1x6 for deck boards?

Width of material: We recommend only 1×4, 5/4×4 or narrower boards. Never use 1×6 or 5/4×6 material in close to ground applications. Spacing between boards: You must allow space for your deck boards to expand when they take on moisture, as they will inevitably do when exposed to wet weather, rain or high humidity.

What size are deck joists?

Commonly used joist sizes are 2-by-6, 2-by-8 and 2-by-10. For example, when you space joists 16″ apart — which is standard for residential decks — a deck spanning 9 1/2′ would require 2-by-6 joists, a 13′ deck would need 2-by-8 joists and a 16′ deck calls for 2-by-10 joists.

Should deck joists be 2x6 or 2x8?

For upper-level decks, 2×10 is recommended as the minimum size to use for strong guard post connections. 2×6 joists should only be used on ground-level decks that do not require, and will not provide for, any guards. … Most decking is not strong enough to support longer spans than 16″.

Is it better to use 2x6 or 5 4 decking?

5/4 x 6 is produced specifically for decking and is milled with a radius edge or bull nose. 2×6 is thicker and is stronger, but is also more expensive. Spacing between deck boards provide a few critical functions.

How wide is 2x8?

Nominal SizeActual Size2x81-1/2″ x 7-1/4″2×101-1/2″ x 9-1/4″2×121-1/2″ x 11-1/4″4×43-1/2″ x 3-1/2″

What size should deck bearers be?

The bearers have to carry the weight of the entire deck and whatever is put on top of it, so they need to be strong. A 140×45 treated pine bearer will usually do the trick. Every 1.2 metres, a 90×90 H4 treated pine post will be needed.

How thick should decking boards be?

Most composite brands have the same thickness, but softwoods and hardwoods will range from 1″ to 2″ thick for decking. Softwoods should be at least 1 1/4 inches thick for a 16″ on center span. 2 inches thick will allow for a 24″ on center span.

What size wood should I use for a deck?

For the deck surface, you can use 2x4s, 2x6s, or 5/4x6s. The 5/4 decking (pronounced “five-quarter”), available in cedar and pressure-treated fir, is 1 inch thick and 5-1/2 inches wide with rounded edges that make for a splinter-free surface. Cedar 1x lumber usually has one rough side and one smooth side.

Can you put deck boards tight together?

Keep the butt ends as tight as possible when installing wood decking. This rule does NOT apply to composite or PVC boards which can have a large thermal expansion; enough to create a serious roller coaster effect down the length of the PVC or composite boards if you DON’T leave room for thermal expansion.

Do you need a gap between decking boards?

Proper Gap between Decking Boards When installing decking boards, make sure to leave 1/4 to 1/8 inch gaps in between them. This gap will make sure that the decking can breathe, have sufficient drainage, and make it easier to clean.

How much space should be between house and deck?

Deck footing for 2×6 and 2×8 joist should be 16″ (400mm) from the house. Deck footings for 2×10 and 2×12 joist should be 24″ (600mm) from the house. There are several reasons for distance between the house and the deck footings. Space is both for ease of installation as well as strength of deck construction.

What does FAS mean in lumber?

FAS: (first and second grade) This stands for the highest grade of lumber. FAS grade includes some defects but is considered the premier lumber for furniture and cabinet making. #1 & #2 common: These two grades will have a fair amount of allowable defects and color variations.

What does BF mean in lumber?

1. Hardwood lumber is typically sold by the board foot, a unit of volume equivalent to a board that is one inch thick, one foot wide and one foot long, or 144 cubic inches.

Why is wood measured in quarters?

The “Quarters” Sizing Method: In the case of rough sawn lumber, the “Quarters” sizing method is usually used by mills that sell rough lumber for woodworking purposes. The “Quarters” method refers only to the thickness of the wood as widths and lengths vary depending on the log the wood is cut from.

Why do 2x4's have rounded edges?

2×4 have rounded edges as it’s very beneficial to the wood itself and those working with it. They reduce the number of injuries like unwanted splinters during the handling and manufacturing process and also ensure that the lumber stays looking its best all throughout until the customer sees it.

Why are the actual dimensions of lumber different from the nominal dimensions?

The “nominal” cross-section dimensions of a piece of lumber, such as 2 X 4 or 1 X 6, are always somewhat larger than the actual, or dressed, dimensions. The reason is that dressed lumber has been surfaced or planed smooth on four sides (called S4S). The nominal measurement is made before the lumber is surfaced.

How wide is a 2x4?

A piece of surfaced (sanded smooth) 2×4 lumber actually measures 1½ inches thick and 3½ inches wide. In rough-cut condition, a 2×4 is slightly less than 2 inches thick and approximately 4 inches wide. When wood is milled from a rough to a smooth surface, it loses about ¼-inch from each of its four sides.

How much should a deck overhang?

The edge of decking should never overhang more than one-third of the decking material. For your standard 5.5” decking, that is 1 ¾” overhang.

How far apart should 4x4 deck posts be?

For Building a Deck Railing, Deck Frame, or Fence The maximum spacing of 4×4 deck posts should be 6 feet on center, while the maximum spacing of 6×6 deck posts should be 8 feet on center.

Can I use 2x8 for deck joists?

2×8 for joists will be fine, with 16″ OC. Should use 2×10 for beams but 2×8 will be fine as well. If you are worried you can triple the 2×8 for the beams but double will be sufficient. You should put the beams at 7 and 14 feet out from the house, with the piers you should do 3 per beam with spacing of 1, 7, 13.

Can you use 1 inch boards for a deck?

Certain tropical hardwoods, like Ipe, for example, are hardier than common pressure-treated woods like cedar or pine. So what size are deck boards made of different types of wood? The standard thickness for all types of wood is 1”, however, for weaker woods, choosing a thicker board can give you a sturdier feel.
